Name: DC48V POE Switch
Brand: Hioso
Price: 1 USD

Brand Name : Hioso

Model Number : Foway2309PFC

Certification : CE, RoHS, CCC

Place of Origin : China, Guang dong

MOQ : 1

Price : Negotiable

Payment Terms : T/T, Western Union, D/P

Supply Ability : 5000pcs/month

Delivery Time : 3-10 working days

Packaging Details : 38X24X18 CM

Item : Poe Switch

Distance : cat5 : 100m

POE : 8 Ports

Port : 2 ports

MTBF : 100000 hours

bit error rate : <1/1000000000

Contact Now

9 Ports PoE Switch 8 10 / 100M PoE Ports + 1 Combo Ports DC48V

Character

Support 8 10/100M RJ45 PoE ports and 1 Combo Uplink
Each PoE port supports auto detect the powered device
Support IEEE802.3af 15.4W and IEEE802.3at 30W PoE standards
Support each port full rate, full-duplex non-blocking forwarding
Support WEB management and SNMP (optional)
8K MAC learning, 1Mbit storage and forward cache space,7.6G back plane bandwidth
Each RJ45 port adopts anti-high voltage circuit, strengthen the lightning protection and anti-interference ability
Supply redundant dual power input ports, enhance reliability
Metal casing with Wall mounting design, external power , better for heat dissipating and installation

Technical Specification

Parameter	Specification
Standard	IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet,IEEE802.3z 1000Base-SX/LX Gigabit Ethernet,IEEE802.3x Flow control,IEEE802.1q VLAN,IEEE802.1p QoS, IEEE802.1d Spanning Tree, IEEE802.3af,IEEE802.3at
PoE	8 10/100M RJ45 PoE/PSE, support IEEE802.3af 15.4W / IEEE802.3at 30W Working mode:auto detect powered device,stop powering if not PD device
Wavelength	850nm/1310nm/1490nm/1550nm/
Transmission distance	100M fiber,multi-mode:2Km;single-mode:25/40/60/80/100/120Km; single-fiber:25/40/60/80/100/120Km; 1000M Fiber,multi-mode:220m(fiber size 62.5/125μm)/550m(fiber size 50/125μm); Single-mode:10/20/40/60/80/100/120Km Single-fiber:10/20/40/60/80/100/120Km CAT5: 100M
Ports	8 10/100M RJ45 ports (POE/PSE): 10/100Mbs 1 1000M Combo port: 1Gbps, 100M/1000M SFP & 10/100/1000M RJ45
MAC	8K
Buffer memory space	1Mbit
Bit error rate	<1/1000000000
MTBF	100000 hours
Power	DC48V dual input redundant backup (external power), AC110V/220V@50HZ/60HZ&DC48V dual input redundant backup(inside power)
Power consumption	Whole device:5W POE/PSE: maximum240W
Working temperature	Common:-10~60℃; -T (wide temperature range):-40~75℃
Storage temperature	-40~80℃
Humidity	5%~90% non-condensing
Installation	Wall mounting type (external power), desk type/1U rack (inside power)
Dimension	30mm (H)×219mm(W)×119mm (D) (external power) 44mm (H)×276mm(W)×190mm (D) (inside power)
